CATV Blue Single Mode LC Fast Connector 55MM Pre Embeded

Brand Name : YT

Model Number : SC APC Singlemode Fast Connector

Certification : ISO, SGS, ROHS

Place of Origin : china shenzhen

MOQ : 10 pcs

Price : Negotiation

Payment Terms : XTransfer T/T, Western Union, PayPal

Supply Ability : 5000 pcs/Month

Delivery Time : 3-7days

Product Name : SCAPC Fiber Optic Connectors

Return Loss : ≥50dB

Tensile Strength : > 10kg

Insert Loss : ≤0.2dB

Length : 55MM

Fiber Type : Single and double mode

Connector Structure : Pre -embeded Type

Contact Now

CATV Singlemode Fiber Optic Lc Fast Connector Assembly

Blue color Singlemode Fiber Optic Quickly assembly/ lc fast connector

Description:
LC Fiber quick connector is designed to simple the connection without fusion splicing machine. This connector is quick assembly which requires only normal fiber preparation tools: cable stripping tool and fiber cleaver.
The connector adopts Fiber Pre-Embedded Tech with superior ceramic ferrule and aluminum alloy V-groove.. Also, transparent design of the side cover which allows visual inspection.
It could be applied to drop cable and indoor cable

Feature:
1). Low insertion loss
2). High return loss (low amounts of reflection at the interface)
3). Ease of installation
4). Low cost
5). Reliability
6). Low environmental sensitivity
7). Ease of use


Product length:50mm ≤L≤60mm



Optical Characteristics



Fast Connector Specification
Mode SM   MM
Polish UPC APC PC
Insertion Loss

ypical ≤0.2dB

Maximum ≤0.3dB

 ≤0.25dB
Return Loss ≥50dB ≥65dB ≥35dB
Interchangeability ≤0.2dB
Repeatability ≤0.1dB
Durability ≤0.2dB (1000 times mating)
Tensile Strengh > 10kg
Temperature ≤0.2dB (-40+85 sustain 100 hours)
Humidity ≤0.2dB (+25+65 93 R.H.100 hours)



Application:


1). CATV
2). Active device termination
3). Telecommunication networks
4). Metro
5). Local Area Networks (LANs)
6). Data processing networks
7). Test equipment
8). Premise installation
9). Wide Area Networks(WANs)
